Survival conditions

Water depth 150 m
Air gap 24 m
Wave height 29 m
Current 1 m/s
Wind speed 49 m/s
Spudcan penetration 3 m

Main tank capacities
Fuel oil 1,779 m3
Drill water 3,320 m3
Potable water 508 m3
Preload 28,212 m3
Liquid mud 1,558 m3
Bulk mud 260 m3
Bulk cement 208 m3
Brine 757 m3
Base oil 509 m3

Variable and combined load
Variable load up to 10,000 t
Combined drilling load:
? Survival 680 t
? Operating 1,400 t

Legs
Leg length 205 m
Leg diameter 18 m
Spudcan area 380 m2

Fixation system
Make GustoMSC
Type 9500

Cantilever system
Type GustoMSC X-Y
Longitudinal reach 27.5 m
Transverse reach 20.0 m

Drilling equipment
Drilling depth 9,144 m
Derrick 60 m - 2,000 kips
Draw works 4,600 hp
Top drive 2,000 hp
Well control equipment 15,000 psi HP/HT
Mud pumps 3 x 2,200 hp, 1 x 800 hp

Machinery/ equipment
Main generator sets 4 x 2,700 kW
Deck cranes 3 x 50 t
